Easy-Torque Handle The heavy-duty, long handle gives plenty of leverage to open or close the vakve against flowing process fluid. Full Port Design Dramatically decreases fluid flow resistance, using the same bore size for both valve internal components and the connecting tube. Elimination of Butted welds reduces contaminant pockets. UHP Cleaning, Packaging, and Testing Final cleaning uses 18meg-ohm Dl water and high-purity nitrogen from a cryogenic source, Every valve is tested with 100% helium across the seat and inboard across the body seals. Pressure Rating Vacuum to 300 psig (20 bar) Test Pressure: 150 psig (10 bar) Leak Test 1x10-8 scc/sec |  |
