Applications
This type of ball valves series is a kind of sanitary valve which used to control the sanitary transfer.t is widely used in food,beverage processing.pharmaceutical and chemial industry area.
Sterilization temperature: 150℃ (Max20min)
Inside surface treatment: Ra≥0.4-0.8um
Surface treatment: Ra20.4-1.6um
The diameter welding: Welding connection: DIN11850-2 &11850-1/SMS/3A/1SO etc
Connection Mode: welding,clamp ,male and female,flange,etc.
Material : Stainless Steel 304,316L
Seal: PTFE,PPL
Easy maintenance, simple structure of the ball valve, sealing ring is generally mobile, disassembly and replacement are more convenient.
